Webots Industrial Workcell ยท Hackathon 2026

Operate Factory Robots with Intent

RobotAbstraction is a Webots-based industrial workcell demo showing how a factory manager can operate robots through natural-language intent instead of low-level commands, powered by Google ADK.

WebotsGoogle ADKReactUR RobotsScaraT6Industrial
Powered by Google ADK Agentic Tool Calling
Robot Abstraction Simulation
Agent Service
Google ADK
Webots Coordinator
UR & ScaraT6 Control
Scroll to explore
๐Ÿค–
4
Robot Models
๐Ÿญ
2
Production Lines
โšก
ADK
Agent Framework
๐ŸŒ
100%
Industrial Focus

Everything you need for Industrial Robotics

A complete workcell demo showing agent-based abstraction, multi-robot coordination, and operator-friendly production control.

Three-Level Abstraction

Separates operator intent, agent tools, and coordinator execution into three clean layers. The operator never touches motor joints or TCP strings โ€” only factory goals.

AbstractionArchitecture

Webots Coordinator

A trusted C supervisor owns all real simulation state. It receives validated high-level commands and translates them into robot-specific UR and SCARA instructions.

WebotsSimulation

Google ADK Agent

The agent service uses Google ADK to map natural-language factory goals to a small, controlled set of workcell tools. One intent, one safe tool call โ€” no raw robot commands.

Google ADKTool Use

Production Line Control

Set operation modes (can priority, fruit priority, balanced), set production targets, enable or disable individual robots, and start/stop lines โ€” all in plain language.

ProductionControl

React SaaS Dashboard

Operators interact through a Vite-powered React dashboard with a chat assistant panel, live production telemetry, and real-time WebSocket feeds from the coordinator.

ReactDashboard

Vendor-Agnostic Commands

Agent tools are robot-agnostic. Adding a new vendor only requires updating the coordinator โ€” the agent interface and operator experience stay identical.

ExtensibleMulti-Vendor

From operator intent to simulation action

A clean three-layer architecture: operator intent, agent tool, coordinator execution.

01

Operator Sends Intent

The factory manager types a natural-language request in the React dashboard. They describe a factory goal โ€” not a robot command.

Python
# Operator types in the dashboard:
Increase can production

# Or:
Sort 6 fruits

# Or:
Disable UR10e for maintenance
02

Agent Maps to Tool

The Google ADK agent service receives the request and selects exactly one safe, robot-agnostic workcell tool that matches the operator's intent.

Python
# agent_service/factory_agent.py

# "Increase can production"
set_operation_mode(mode="can_priority")

# "Sort 6 fruits"
set_production_target(item_type="fruits", count=6)

# "Disable UR10e"
disable_robot(robot="UR10e")
03

Bridge Forwards Command

The Node.js bridge validates the tool action and sends a structured CONTROL command over TCP to the Webots coordinator.

Python
# frontend/server.mjs bridges tool โ†’ coordinator

# set_operation_mode(mode="can_priority")
# becomes:
CONTROL MODE CAN_PRIORITY

# disable_robot(robot="UR10e")
# becomes:
CONTROL DISABLE UR10e
04

Coordinator Executes

The Webots coordinator applies the command to the simulation: adjusting conveyor speeds, sequencing UR arm phases, and sending SCARA_* messages โ€” all without agent involvement.

Python
# combined_world/controllers/coordinator/coordinator.c

# On MODE CAN_PRIORITY:
# - Increase can conveyor speed
# - Reduce fruit/SCARA priority
# - Send CMD to UR executors

# Telemetry flows back to dashboard:
STATE / COUNT / LOG

Factory intent.
Safe workcell action.

The agent service uses Google ADK, defining robot-agnostic tools that map operator language to safe coordinator commands. The coordinator handles all robot-specific details inside Webots.

< 1s
Agent Response
4 Robots
Robot Models
Full
Abstraction
Start Agent Servicepython agent_service/server.py
factory_agent.pyPython
# agent_service/factory_agent.py

from google.adk.agents import Agent
from google.adk.tools import tool

@tool
def set_operation_mode(mode: str) -> dict:
    """Set the workcell operation mode.
    modes: can_priority | fruit_priority | balanced | high_capacity | low_power
    """
    return {"action": "set_operation_mode", "mode": mode}

@tool
def set_production_target(item_type: str, count: int) -> dict:
    """Set a production target for cans or fruits."""
    return {"action": "set_production_target", "item_type": item_type, "count": count}

@tool
def disable_robot(robot: str) -> dict:
    """Take a robot offline. robots: UR3e | UR5e | UR10e | ScaraT6"""
    return {"action": "disable_robot", "robot": robot}

@tool
def enable_robot(robot: str) -> dict:
    """Bring a robot back online."""
    return {"action": "enable_robot", "robot": robot}

@tool
def get_workcell_status() -> dict:
    """Return a production report for the current workcell state."""
    return {"action": "get_workcell_status"}

factory_agent = Agent(
    model="gemini-2.0-flash",
    tools=[set_operation_mode, set_production_target,
           disable_robot, enable_robot, get_workcell_status],
)
Terminal output
$ python agent_service/server.py
RobotAbstraction agent ready. Listening on :8787
> Increase can production
[agent] set_operation_mode(mode="can_priority")
[bridge] CONTROL MODE CAN_PRIORITY
[coordinator] can conveyor speed increased
โ–Š

The Workcell Robots

The RobotAbstraction workcell combines a Universal Robots can-handling cell and an Epson ScaraT6 fruit-sorting cell in a shared Webots world.

๐Ÿฆพ
Simulated
Industrial Arm Cell

Universal Robots โ€” Can Cell

Three Universal Robots arms (UR3e, UR5e, UR10e) operate the can-handling production line. The coordinator sequences each arm phase and adjusts conveyor speed based on the current operation mode.

UR3eUR5eUR10eConveyorCan Handling
๐ŸŠ
Simulated
SCARA Robot

Epson ScaraT6 โ€” Fruit Cell

An Epson ScaraT6 robot handles the fruit-sorting production line. The coordinator sends SCARA_* messages to the Python controller which manages its motion phases independently of the UR cell.

ScaraT6Fruit SortingSCARA ControlPhase Sequencing
๐Ÿ† TechEx Hackathon 2026 ยท Robotics & Simulation Track

Ready to explore
agentic workcell control?

Clone the repository, launch Webots with the combined world, start the agent service and dashboard. Everything is open-source and ready to run.

Open Source
Python 3.12+
